FPC-P2
FAITHFUL
Photoresist (shading) test principle specified by the Intemational HydraulicStandards Committee;
High-precision laser sensor with wide test range, stable performance, low noiseand high resolution:High-precision bidirectional plunger pump sampling method, adjustable injectionspeed, and high sampling volume accuracy:;
The pipeline is made of 316L and PTFE materials to meet the detection of variousorganic solvents and oil products;
Can be connected to an extemal pressure chamber to fom positive/negativepressure to detect high viscosity samples and degas the samples;.
A variety of sampling containers can be used or directly connected to the hydraulic system to meet the testing requirements of different industries:
Built-in multiple calibration curves, compatible with all commonly used domestic and foreign standards for calibration:
Built-in multiple common standards such as GJB-420A,GJB-420B, NAS1638,1S04406, SAE4059E and FOCT17216supports custom standard testing,
Built-in data analysis system, and can set the required standards according to customerneeds and complete sample grade determination; data avallable Automatic processing and printing functions:
1000 particle size channels can be set to facilitate particle size analysis:
Color touch screen, Chinese and English dual interface:
RS232 interface can be connected to a computer or laboratory platform for data processing, or UsB can be used for data storage:
Built-in lithium battery, no external power supply required.
Photoresist (shading) test principle specified by the Intemational HydraulicStandards Committee;
High-precision laser sensor with wide test range, stable performance, low noiseand high resolution:High-precision bidirectional plunger pump sampling method, adjustable injectionspeed, and high sampling volume accuracy:;
The pipeline is made of 316L and PTFE materials to meet the detection of variousorganic solvents and oil products;
Can be connected to an extemal pressure chamber to fom positive/negativepressure to detect high viscosity samples and degas the samples;.
A variety of sampling containers can be used or directly connected to the hydraulic system to meet the testing requirements of different industries:
Built-in multiple calibration curves, compatible with all commonly used domestic and foreign standards for calibration:
Built-in multiple common standards such as GJB-420A,GJB-420B, NAS1638,1S04406, SAE4059E and FOCT17216supports custom standard testing,
Built-in data analysis system, and can set the required standards according to customerneeds and complete sample grade determination; data avallable Automatic processing and printing functions:
1000 particle size channels can be set to facilitate particle size analysis:
Color touch screen, Chinese and English dual interface:
RS232 interface can be connected to a computer or laboratory platform for data processing, or UsB can be used for data storage:
Built-in lithium battery, no external power supply required.
Model | LPC-P2 |
Light Source | Semiconductor laser |
Particle Size Range | 0.8-600μm (depending on different sensors) |
Sensitivity | 0.1μm |
Custom Detection Channel | 8+8 channels, arbitrarily set particle size |
Sampling Volume | 0.2-1000ml, interval 0.1mL |
Sampling Accuracy | ≤±1% |
Sampling Speed | 5-80mL/min |
Cleaning Speed | 5-80mL/min |
Cleaning Volume | Can be set between 0~90mL |
Counting Accuracy | <±5% |
Resolution | ≤10% |
Repeatability | RSD<2% |
Limit Coincidence error | 12000-40000 capsules/mL |
Offline Detection Of Viscosity | ≤100cSt |
Pressure Range | Low pressure 0-0.6Mpa, high pressure up to 42Mpa |
Online Detection Interval | arbitrarily set |
Test sample temperature | 0℃~80℃ |
Working temperature | -20℃~60℃ |
Storage temperature | -30℃~80℃ |
Screen size | 7 inch |
Power supply | AC100-240V, 50/60Hz |
Battery capacity | 5200mAh |
Battery running time | 6-8 hours |
Dimensions | 310x305x135mm |
Weight | 7.5kg (including battery) |
Model | LPC-P2 |
Light Source | Semiconductor laser |
Particle Size Range | 0.8-600μm (depending on different sensors) |
Sensitivity | 0.1μm |
Custom Detection Channel | 8+8 channels, arbitrarily set particle size |
Sampling Volume | 0.2-1000ml, interval 0.1mL |
Sampling Accuracy | ≤±1% |
Sampling Speed | 5-80mL/min |
Cleaning Speed | 5-80mL/min |
Cleaning Volume | Can be set between 0~90mL |
Counting Accuracy | <±5% |
Resolution | ≤10% |
Repeatability | RSD<2% |
Limit Coincidence error | 12000-40000 capsules/mL |
Offline Detection Of Viscosity | ≤100cSt |
Pressure Range | Low pressure 0-0.6Mpa, high pressure up to 42Mpa |
Online Detection Interval | arbitrarily set |
Test sample temperature | 0℃~80℃ |
Working temperature | -20℃~60℃ |
Storage temperature | -30℃~80℃ |
Screen size | 7 inch |
Power supply | AC100-240V, 50/60Hz |
Battery capacity | 5200mAh |
Battery running time | 6-8 hours |
Dimensions | 310x305x135mm |
Weight | 7.5kg (including battery) |
