Product Description
1. Unique vertical double duct supply horizontal air circularly.
2. 4 grades 3 speed adjustable speed fan, LED running indicator light.
3. Over-temperature protection system: LED red light on meanwhile cut off heating circuit to improve product safety when workroom temperature exceed the alarm value.
4. High precision digital independent temperature limiter.
5.Equipment used for biology and microbiology laboratory applications like bacteriological and culture studies by
controlling temperature and ventilation.
6. 220 V ± 10 %, 50/60 Hz
7. Microprocessor controlled equipment
8. Forced air circulation by air turbine with noise no greater than 70 dB
9. Double doors (inner glass, outer stainless steel)
Product Description
1. Unique vertical double duct supply horizontal air circularly.
2. 4 grades 3 speed adjustable speed fan, LED running indicator light.
3. Over-temperature protection system: LED red light on meanwhile cut off heating circuit to improve product safety when workroom temperature exceed the alarm value.
4. High precision digital independent temperature limiter.
5.Equipment used for biology and microbiology laboratory applications like bacteriological and culture studies by
controlling temperature and ventilation.
6. 220 V ± 10 %, 50/60 Hz
7. Microprocessor controlled equipment
8. Forced air circulation by air turbine with noise no greater than 70 dB
9. Double doors (inner glass, outer stainless steel)
Model | WPL- 30BE | WPL- 45BE | WPL- 65BE | WPL- 85BE | WPL- 125BE | WPL- 230BE | |
WPL- 30BE(304) | WPL- 45BE(304) | WPL- 65BE(304) | WPL- 85BE(304) | WPL- 125BE(304) | WPL-230BE(304) | ||
Cycle Mode | Forced convection | ||||||
Function | Temp. range | RT+5-120℃ | |||||
Temp. Resolution Ratio | 0.1℃ | ||||||
Temp. Motion | ±1℃ | ||||||
Temp. Uniformity | ±1.0℃ | ||||||
Structure | Inner Chamber | Mirror Stainless Steel | |||||
Outer Shell | AISI304 | ||||||
Insulation layer | High quaility foam board | ||||||
Heater | Stainless steel electric heating tube | ||||||
Power rating | 0.4kW | 0.5kW | 0.7kW | 0.9kW | 1.1kW | 1.5kW | |
Exhaust hole | φ35mm top( with function of test hole) | ||||||
Controller | Temp control mode | Two temperature section intelligent PID | |||||
Temp. setting mode | Touch button setting | ||||||
Temp. display mode | Measuring temperature: LCD upper screen; setting temperature: the lower row | ||||||
Timer | 0-9999min(with timing wait function) | ||||||
Operation function | Fixed temperature operation, timing function, auto stop. | ||||||
Additional function | Digital Independent temp.limiter.4 grades 3 speed ajustable speed fan (230 without fan speed adjuor) Sensor deviation correction,temperature overshoot self-tuning,internal parameter locking,power-off parameter memory | ||||||
Sensor | pt100 | ||||||
Safety device | Over temp. sound-light alarm, digital independent temp, limiter | ||||||
Specification | Inner Chamber size(W*L*H)(mm) | 310*310 *310 | 350*350 *350 | 400*360 *450 | 450*420 *450 | 500*450 *550 | 600*500 *750 |
Exterior size (W*L*H)(mm) | 460*510 *695 | 500*550 *735 | 550*550 *840 | 590*610 *830 | 636*680 *915 | 735*835 *1115 | |
Packing size (W*L*H)(mm) | 540*575 *855 | 580*615 *895 | 635*625 *995 | 680*685 *1000 | 710*730 *1100 | 857*885 *1287 | |
Volume | 30L | 45L | 65L | 85L | 125L | 230L | |
Shelf number | 5 | 6 | 8 | 8 | 11 | 17 | |
Load per rack | 15kg | ||||||
Shelf space | 40mm | ||||||
Current rating | 220V/ 1.8A | 220V/ 2.3A | 220V/ 3.2A | 220V/ 4.1A | 220V/ 5A | 220V/ 6.8A | |
NW/GW (kg) | 33/37 | 37/43 | 44/49 | 50/56 | 60/66 | 94/120 | |
Shelf fame | 4 | ||||||
Shelf AISI304 | 2 | ||||||
optional accessories | Shelf, U-disk storage, Printer, 3.5 inch color touch screen temperature controller |
Model | WPL- 30BE | WPL- 45BE | WPL- 65BE | WPL- 85BE | WPL- 125BE | WPL- 230BE | |
WPL- 30BE(304) | WPL- 45BE(304) | WPL- 65BE(304) | WPL- 85BE(304) | WPL- 125BE(304) | WPL-230BE(304) | ||
Cycle Mode | Forced convection | ||||||
Function | Temp. range | RT+5-120℃ | |||||
Temp. Resolution Ratio | 0.1℃ | ||||||
Temp. Motion | ±1℃ | ||||||
Temp. Uniformity | ±1.0℃ | ||||||
Structure | Inner Chamber | Mirror Stainless Steel | |||||
Outer Shell | AISI304 | ||||||
Insulation layer | High quaility foam board | ||||||
Heater | Stainless steel electric heating tube | ||||||
Power rating | 0.4kW | 0.5kW | 0.7kW | 0.9kW | 1.1kW | 1.5kW | |
Exhaust hole | φ35mm top( with function of test hole) | ||||||
Controller | Temp control mode | Two temperature section intelligent PID | |||||
Temp. setting mode | Touch button setting | ||||||
Temp. display mode | Measuring temperature: LCD upper screen; setting temperature: the lower row | ||||||
Timer | 0-9999min(with timing wait function) | ||||||
Operation function | Fixed temperature operation, timing function, auto stop. | ||||||
Additional function | Digital Independent temp.limiter.4 grades 3 speed ajustable speed fan (230 without fan speed adjuor) Sensor deviation correction,temperature overshoot self-tuning,internal parameter locking,power-off parameter memory | ||||||
Sensor | pt100 | ||||||
Safety device | Over temp. sound-light alarm, digital independent temp, limiter | ||||||
Specification | Inner Chamber size(W*L*H)(mm) | 310*310 *310 | 350*350 *350 | 400*360 *450 | 450*420 *450 | 500*450 *550 | 600*500 *750 |
Exterior size (W*L*H)(mm) | 460*510 *695 | 500*550 *735 | 550*550 *840 | 590*610 *830 | 636*680 *915 | 735*835 *1115 | |
Packing size (W*L*H)(mm) | 540*575 *855 | 580*615 *895 | 635*625 *995 | 680*685 *1000 | 710*730 *1100 | 857*885 *1287 | |
Volume | 30L | 45L | 65L | 85L | 125L | 230L | |
Shelf number | 5 | 6 | 8 | 8 | 11 | 17 | |
Load per rack | 15kg | ||||||
Shelf space | 40mm | ||||||
Current rating | 220V/ 1.8A | 220V/ 2.3A | 220V/ 3.2A | 220V/ 4.1A | 220V/ 5A | 220V/ 6.8A | |
NW/GW (kg) | 33/37 | 37/43 | 44/49 | 50/56 | 60/66 | 94/120 | |
Shelf fame | 4 | ||||||
Shelf AISI304 | 2 | ||||||
optional accessories | Shelf, U-disk storage, Printer, 3.5 inch color touch screen temperature controller |
